The manual injection machine is designed for robust production, with adjustable components to accommodate different mould requirements. Its heavy-duty frame, precision-machined barrel, adjustable nozzle height and mould locking system make it suitable for educational settings, small businesses and plastic recycling applications.
|
120 g
Capacity per shot
|
55 kg
Machine weight
|
400°C
PID temperature range
|
220/110 V
Voltage
|
| Heavy-duty frame Heavy channel frame designed for long service life. |
Portable construction The machine can be dismantled and transported easily. |
| Precision-machined barrel Thicker barrel walls support even heat distribution. |
Adjustable nozzle height Nozzle height can be adjusted according to the mould. |
| Mould locking system Mould placement and locking system designed for a smooth production cycle. |
Adjustable setup Setup can be adjusted according to the mould being used. |
| Temperature control Multispan PID controller with a stated temperature range up to 400°C. |
Technical assistance Virtual training, installation assistance and technical support are provided. |
| Specification | Detail |
|---|---|
| Machine type | Manual injection machine |
| Barrel diameter | 33 mm |
| Barrel length | 400 mm |
| Plunger diameter | 32 mm |
| Plunger length | 410 mm |
| Nozzle bore | 6 mm |
| Heater size | 40 × 100 mm |
| Temperature controller | Multispan PID, up to 400°C, single unit |
| Machine weight | 55 kg |
| Voltage | 220/110 V |
| Flake input | Small / Medium |
| Capacity | 120 g per shot |
| Setup | Adjustable according to the mould |
| Compatible materials | HDPE, LDPE, PP, PS, PLA and ABS |
